SIEMENS Q230GF 30 Amp 2-Pole Ground Fault Circuit Breaker (GFCI) Circuit Breaker Replaces QF230A

Brand: SIEMENS

Features:

• Device intended for personnel protection from Ground Fault
• LED trip indicators to help identify fault conditions
• Ideal for wet and damp locations such as pools, spas, HVAC, kitchen and bathroom circuits
• Reduced size breaker allows for more wire bending space
• Type QPFB circuit breaker, replaces Siemens model QF230AP and QF230A

model number: Q230GF

Part Number: Q230GF

Details: Siemens GFCI circuit breakers are UL Listed and cUL Certified to provide Class A GFCI protection. Current imbalances of 4-6 mA or more between load conductors will cause the ground fault sensor to trip the circuit breaker. These circuit breakers offer Self-Test and Lockout features as required by UL 943, enabling the GFCI to automatically and continuously test itself to ensure that it is working properly. If it is detected that the device has been compromised, the device trips itself signaling to the homwoener it must be replaced to help guarentee the best protection. 10,000 AIR rated breaker and designed for use with 120/240-Volt AC systems.

EAN: 0195125299979

Package Dimensions: 6.3 x 4.0 x 2.8 inches
