About this item

• Constant Current LED driver
• Rated supply voltage: 120–277V AC
• Output Power: 34W (Max.)
• Max. output voltage 60 V DC
• Dimmable via 0-10V interface / Dimming range 10–100 %

Tridonic 34W LED Driver – Constant Current, 0–10V Dimmable

The Tridonic 34W LED Driver from the Linear Essence Series offers dependable performance and dimming control for constant current LED applications in the U.S. With high efficiency, adjustable output, and long operating life, it’s ideal for commercial lighting environments.

Smooth 0–10V Dimming with the Tridonic 34W LED Driver

This driver supports 0–10V dimming from 10% to 100%, providing precise light control and compatibility with a wide range of LED fixtures. It meets DesignLights Consortium (DLC) 4.3 standards and carries UL Listed Class P certification.

Adjustable Output for Flexible LED Compatibility

The Tridonic 34W LED Driver allows you to select between 690mA and 825mA output current, giving you flexibility for various fixture types. With a maximum output power of 34W, it balances energy efficiency and performance.

Built for Safety and Long-Term Use

The driver includes overload, short-circuit, no-load, and overtemperature protection to safeguard your lighting system. Its rated lifetime of up to 50,000 hours and 5-year warranty ensure long-term reliability.

Product Features

• Tridonic Linear Essence Series 34 Watts Constant Current LED driver
• Only for US applications
• Dimmable via 0-10V interface
• Dimming range 10–100 %
• Class 2
• Meets DesignLights Consortium 4.3
• Certified to UL Listed Class P
• Adjustable output current 690 or 825 mA
• Max. Output power 34 W
• Lifetime up to 50,000 hrs
• Product Weight: 6.2oz
• Product Dimensions (L x W x H): 11.00" x 1.10" x 0,90" in.
• Quantity: 1
• 5-Years Warranty

Technical Specifications

• Type: Constant Current
• Output Power: 34W (Max.)
• Rated supply voltage: 120–277V AC
• AC voltage range: 108–305V AC
• Mains frequency: 50/60 Hz
• Max. output voltage 60 V DC
• Dimming range 10–100 %
• IP Rating: IP20

Housing properties

• Casing: Metal, White
• Type of Protection IP20
• Dry and Damp location

Functions of the 34W LED Driver

• Overload protection
• Short-circuit protection
• No-load protection
• Overtemperature protection
